Name: Township Range Section Rancho Boundaries

Display Field: NAME_2

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: This dataset contains the boundaries of the Public Land Survey System (PLSS) – Township Range Section boundaries, as well as the boundaries of the Ranchos and Landgrants that pre-dated the PLSS. In general these match the USGS topographic Quad Sheets from the US Geological Survey.

Copyright Text: Los Angeles County, USGS, PLSS, El Segundo

Default Visibility: false

MaxRecordCount: 1000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 1155582

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 6265677.400284097
YMin: 1615077.453521505
XMax: 6711391.894023925
YMax: 2183087.1009645015
Spatial Reference: 102645  (2229)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: FeatType
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Rancho
  Label: Rancho
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [0, 0, 0, 0]
  Outline:
  Style: esriSLSSolid
  Color: [0, 197, 255, 255]
  Width: 2
• Value: TRS
  Label: TRS
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [0, 0, 0, 0]
  Outline:
  Style: esriSLSSolid
  Color: [255, 0, 0, 255]
  Width: 1
Transparency: 0
Labeling Info:
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: [LANDGRANT]
Use Coded Values: true
Symbol:
Color: [0, 132, 168, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Arial
Font Style: normal
Font Weight: bold
Font Decoration: none

Min. Scale: 288896.0
Max. Scale: 0.0
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: [TOWNSHIP] CONCAT "-" CONCAT [RANGE] CONCAT "-" CONCAT [SECTION]
Use Coded Values: true
Symbol:
Color: [230, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 9
Font Family: Tahoma
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 36113.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• GRANT_NO ( type: esriFieldTypeDouble, alias: GRANT_NO )
• ACRES ( type: esriFieldTypeDouble, alias: ACRES )
• SECTION ( type: esriFieldTypeDouble, alias: SECTION )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• LANDGRANT ( type: esriFieldTypeString, alias: LANDGRANT, length: 100 )
• NAME_2 ( type: esriFieldTypeString, alias: NAME_2, length: 254 )
• GRANTEE__P ( type: esriFieldTypeString, alias: GRANTEE__P, length: 254 )
• PATENTEE__ ( type: esriFieldTypeString, alias: PATENTEE__, length: 254 )
• GRANTED ( type: esriFieldTypeString, alias: GRANTED, length: 254 )
• PATENT_DAT ( type: esriFieldTypeString, alias: PATENT_DAT, length: 254 )
• SURVEYOR ( type: esriFieldTypeString, alias: SURVEYOR, length: 254 )
• SURVEY_DAT ( type: esriFieldTypeString, alias: SURVEY_DAT, length: 254 )
• CO ( type: esriFieldTypeString, alias: CO, length: 254 )
• TYPE ( type: esriFieldTypeString, alias: TYPE, length: 254 )
• MERIDIAN ( type: esriFieldTypeString, alias: MERIDIAN, length: 10 )
• TOWNSHIP ( type: esriFieldTypeString, alias: TOWNSHIP, length: 5 )
• RANGE ( type: esriFieldTypeString, alias: RANGE, length: 5 )
• NOTES ( type: esriFieldTypeString, alias: NOTES, length: 50 )
• FeatType ( type: esriFieldTypeString, alias: FeatType, length: 10 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
