Name: River, Channel or Stream

Display Field: GNIS_Name

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: The National Hydrography Dataset (NHD) - link to USGS website - is a feature-based database that interconnects and uniquely identifies the stream segments or reaches that make up the nation's surface water drainage system. NHD data was originally developed at 1:100,000 scale and exists at that scale for the whole country. High resolution NHD adds detail to the original 1:100,000-scale NHD. (Data for Alaska, Puerto Rico and the Virgin Islands was developed at high-resolution, not 1:100,000 scale.) Like the 1:100,000-scale NHD, high resolution NHD contains reach codes for networked features and isolated lakes, flow direction, names, stream level, and centerline representations for areal water bodies. Reaches are also defined to represent waterbodies and the approximate shorelines of the Great Lakes, the Atlantic and Pacific Oceans and the Gulf of Mexico. The NHD also incorporates the National Spatial Data Infrastructure framework criteria set out by the Federal Geographic Data Committee.NHD is used with other data themes such as elevation, boundaries, and transportation to produce general reference maps. The NHD is often used by scientists using GIS technology. GIS takes advantage of a rich set of attributes that can be processed to generate specialized information. These analyses are possible because the NHD contains a flow direction network that traces the water downstream or upstream. The NHD also uses an addressing system to link specific information about the water such as discharge rates, water quality, and fish population. Using the basic NHD attributes, flow network, linked information, and other characteristics, it is possible to study cause and affect relationships such as how a source of poor water quality upstream might affect a fish population downstream. The features in the NHD are organized into polygons, lines and points. The polygons most commonly portray waterbodies such as lakes while lines commonly portray streams. The stream lines are broken into shorter segments stretching from confluence-to-confluence. The segments are then linked together to trace the flow of water across the landscape. Flowlines attributed as artificial paths are added inside water bodies to maintain the flow network.

Copyright Text: U.S. Geological Survey, U.S. Department of Agriculture, and Natural Resources Conservation Service

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 36112

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 6271233.951256484
YMin: 1385503.2624971478
XMax: 6670108.461930484
YMax: 2123323.7168913903
Spatial Reference: 102645  (2229)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [0, 182, 241, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: FType

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Permanent_Identifier ( type: esriFieldTypeString, alias: Permanent Identifier, length: 40 )
• FDate ( type: esriFieldTypeDate, alias: Date, length: 8 )
• Resolution ( type: esriFieldTypeInteger, alias: Resolution , Coded Values: [1: Local] , [2: High] , [3: Medium] )
• GNIS_Name ( type: esriFieldTypeString, alias: Name, length: 65 )
• LengthKM ( type: esriFieldTypeDouble, alias: Length Km )
• ReachCode ( type: esriFieldTypeString, alias: Reach Code, length: 14 )
• FlowDir ( type: esriFieldTypeInteger, alias: Flow Direction , Coded Values: [0: Uninitialized] , [1: WithDigitized] )
• FType ( type: esriFieldTypeInteger, alias: Type )
• FCode ( type: esriFieldTypeInteger, alias: Code , Coded Values: [56600: Coastline] )
• MainPath ( type: esriFieldTypeInteger, alias: Main Path , Coded Values: [0: Unspecified] , [1: Confluence Main] , [2: Divergence Main] , ...1 more... )
• InNetwork ( type: esriFieldTypeInteger, alias: In Network , Coded Values: [0: No] , [1: Yes] )
• DESCRIPTIO ( type: esriFieldTypeString, alias: Description, length: 254 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )

Types:

ID: 566
Name: Coastline
Domains:
• Resolution:
  Inherited
• FlowDir:
  Inherited
• FCode:
  Inherited
• MainPath:
  Inherited
• InNetwork:
  Inherited
• VisibilityFilter:
  Inherited

---

ID: 558
Name: ArtificialPath
Domains:
• Resolution:
  Inherited
• FlowDir:
  Inherited
• FCode:
  Coded Values: [55800: Artificial Path]
• MainPath:
  Inherited
• InNetwork:
  Inherited
• VisibilityFilter:
  Inherited

---

ID: 428
Name: Pipeline
Domains:
• Resolution:
  Inherited
• FlowDir:
  Inherited
• FCode:
  Coded Values: [42800: Pipeline] , [42816: Pipeline: Pipeline Type = Aqueduct] , [42801: Pipeline: Pipeline Type = Aqueduct; Relationship to Surface = At or Near] , ...19 more...
• MainPath:
  Inherited
• InNetwork:
  Inherited
• VisibilityFilter:
  Inherited

---

ID: 336
Name: CanalDitch
Domains:
• Resolution:
  Inherited
• FlowDir:
  Inherited
• FCode:
  Coded Values: [33600: Canal Ditch] , [33601: Canal Ditch: Canal Ditch Type = Aqueduct] , [33603: Canal Ditch: Canal Ditch Type = Stormwater]
• MainPath:
  Inherited
• InNetwork:
  Inherited
• VisibilityFilter:
  Inherited

---

ID: 420
Name: Underground Conduit
Domains:
• Resolution:
  Inherited
• FlowDir:
  Inherited
• FCode:
  Coded Values: [42000: Underground Conduit] , [42001: Underground Conduit: Positional Accuracy = Definite] , [42002: Underground Conduit: Positional Accuracy = Indefinite] , ...1 more...
• MainPath:
  Inherited
• InNetwork:
  Inherited
• VisibilityFilter:
  Inherited

---

ID: 460
Name: StreamRiver
Domains:
• Resolution:
  Inherited
• FlowDir:
  Inherited
• FCode:
  Coded Values: [46000: Stream/River] , [46003: Stream/River: Hydrographic Category = Intermittent] , [46006: Stream/River: Hydrographic Category = Perennial] , ...1 more...
• MainPath:
  Inherited
• InNetwork:
  Inherited
• VisibilityFilter:
  Inherited

---

ID: 334
Name: Connector
Domains:
• Resolution:
  Inherited
• FlowDir:
  Inherited
• FCode:
  Coded Values: [33400: Connector]
• MainPath:
  Inherited
• InNetwork:
  Inherited
• VisibilityFilter:
  Inherited

---

ID: 468
Name: Drainageway
Domains:
• Resolution:
  Inherited
• FlowDir:
  Inherited
• FCode:
  Coded Values: [46800: Drainageway]
• MainPath:
  Inherited
• InNetwork:
  Inherited
• VisibilityFilter:
  Inherited

---

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
